Linear Regulators & Bandgap Solutions

Omni Design offers a family of support IP and solutions including bandgap references, internally compensated and externally compensated LDOs supporting process nodes from advanced FinFET nodes to 28nm. Omni Design's offerings are characterized by capabilities such as capless operation, superior Power Supply Rejection Ratio (PSRR), and low noise.

LDOs are considered optimal power supply IP for sensitive analog circuits that necessitate high voltage accuracy and minimal noise. They are frequently deployed as Point-of-Load (PoL) regulators, strategically placed in close proximity to the target IP block to deliver clean, regulated power. Beyond their fundamental role in voltage regulation, LDOs also function as crucial filters. They effectively suppress ripple and noise originating from upstream switching converters, thereby safeguarding sensitive downstream loads from adverse power supply conditions.

Omni Design Technologies provides a comprehensive family of support IP, encompassing linear regulators (LDOs) and bandgap solutions. Omni Design's portfolio also features precision voltage and current references, which leverage proprietary architectures to achieve high power supply rejection across ultra-wide bandwidths, a capability essential for high-speed data converters. These references are engineered for high performance without requiring calibration or programming, although programming flexibility is available if needed.

High-Performance Solutions

Internally compensated options

Seamless integration with
ADC’s & DAC’s

Available in FinFET
nodes to 28nm

Value Proposition

Advanced Control Techniques for Superior Performance

Omni Design’s low dropout (LDO) linear regulators incorporate advanced control techniques to achieve excellent transient response, superior PSRR performance and low noise. Our design philosophy directly addresses the critical performance parameters to deliver high-quality power for high-performance mixed signal sub-systems.

Capless LDO Solutions with Integrated Pass Transistors

Omni Design offers capless low dropout regulators (LDOs) for efficient power management. These internally compensated LDO solutions are designed with an integrated pass transistor and maintain stability with an on-chip capacitor of up to 1nF. This on-chip stability is a key enabler for capless operation, significantly reducing the reliance on bulky external components. Capless LDOs showcase a range of output current capabilities from 60mA to 300mA and support for various advanced FinFET process nodes and foundries.

For applications with specific compensation requirements, Omni Design also provides externally compensated LDOs, which are stable with a minimum of 10uF external capacitance.

Seamless Integration Capabilities

A crucial aspect of our value proposition is the ease with which our LDOs integrate with Omni Design's own ADCs and DACs. Additionally we offer highly integrated Analog Front-End (AFE) solutions that include LDOs, PVT monitoring, references, and clock management. Our integrated approach simplifies the design process for customers developing complex mixed-signal SoCs.
